Concrete Drilling Range(mm) | Rated Voltage(v) | Rated Frequency(Hz) |
Rated Input Power(w) |
No-load Speed(rpm) | Cable length(m) | Borehole Depth(mm) |
Net/Gross Weight(Kgs) |
Packing Size(cm) | |
|---|---|---|---|---|---|---|---|---|---|---|
| OND-940 | ~16”(~400) | 110/220~ | 50-60 | 5180 | 313 | 3.5 | 600 | 25.5/28.5 | 104*38*24 | 1000 |
| OND-940E | ~16”(~400) | 110/220~ | 50-60 | 5180 | 100-313 | 3.5 | 600 | 25.5/28.5 | 104*38*24 | 1000 |
| OND-945 | ~18”(~450) | 110/220~ | 50-60 | 5380 | 260 | 3.5 | 600 | 26.5/29.5 | 104*38*24 | 1000 |
| OND-945E | ~18”(~450) | 110/220~ | 50-60 | 5380 | 100-260 | 3.5 | 600 | 26.5/29.5 | 104*38*24 | 1000 |
| OND-950 | ~20”(~500) | 110/220~ | 50-60 | 5580 | 260 | 3.5 | 600 | 27.5/30.5 | 104*38*24 | 1000 |
| OND-950E | ~20”(~500) | 110/220~ | 50-60 | 5580 | 100-260 | 3.5 | 600 | 27.5/30.5 | 104*38*24 | 1000 |
